Product description
The BOXY Autoloader ROBORATOR V1 is a modern robotic cell designed to automate the operation of CNC machines, such as small and medium-sized machine tools and cylindrical grinders. The standard model comes complete with all the necessary hardware and integration with the selected machine, offering an exceptionally competitive price-to-performance ratio.
Why choose ROBORATOR?
- Independence from employee availability – automation reduces the risk of staff shortages,
- Long work cycles in automated mode – work without operator supervision,
- No need to program the robot – just define the process once,
- Improved productivity and fuller utilization of machine operating time,
- Ability to work 7 days a week, 24 hours a day – without breaks,
- Repeatability and stable production quality,
- Compact design – takes up little space,
- Easy relocation thanks to one common base,
- Maintaining the ability to perform manual work,
- Full safety – the system and the station are CE marked,
- Quick installation and changeover – minimizing downtime,
- Universality – compatibility with machine tools from various brands and suppliers.
Application
- Lathes up to 8",
- Vertical machining centers (e.g. Brother, Fanuc),
- Drilling and tapping centers,
- Cylindrical grinders.
Functions and operation
The BOXY Autoloader ROBORATOR is a solution designed for rapid loading and unloading of workpieces using an industrial robot on CNC machine tools. The device provides maximum efficiency while maintaining ease of use, eliminating the challenges associated with traditional table-top systems.
Key elements and features
- A system of drawers with dimensions of 600 × 400 mm with a load capacity of 50 kg each, enabling the storage of details,
- Possibility of working for many hours without an operator,
- Compact design, taking up little space compared to large special systems,
- Short installation time and easy changeover, which facilitates process automation,
- Versatility – ability to operate various types of machines on production lines,
- One-body construction allows for quick delivery and commissioning.
SoftBox software
- Quick and automatic programming functions,
- User-friendly interface – operation is also possible by unskilled operators,
- Possibility of adaptation to various details and production series.
Additional benefits
- Loading and unloading of elements without having to stop the robot,
- Proven solutions based on many years of industry experience.
BOXY Autoloader ROBORATOR V1 is the perfect solution for companies that want to increase efficiency, repeatability and safety in CNC processes, while minimizing investment costs and saving production space.
Technical Parameters
| SKU: | Roborator V1-3 |
|---|---|
| Brand: | CNC Ileri |
| Pallet width (mm): | 400.00 |
| Number of pallets: | 3.00 |
| Pallet length (mm): | 600.00 |
| Workpiece weight (wrist) (kg): | 7.00 |
| Workpiece inspection station: | Tak |
| Software: | SoftBoxy |
| Maximum robot payload (kg): | 7.00 |
| Reach radius in (mm): | 911.00 |
| Number of drawers: | 3.00 |
| Maximum load capacity per drawer (kg): | 50.00 |
| Maximum workpiece height (mm): | 80.00 |
| Number of axes: | 6 |
| Workpiece magazine type: | szufladowy |
| Drawer dimensions (mm): | 600 x 400 |
| Workpiece inspection station: | tak |
| Loading / unloading function during robot operation: | tak |
| Air blow function: | tak |
| Gripper tower: | tak (kondżektor, chwytaki, palce) |
| Software packages: | Softboxy, Easysoft, Autoteach |
| Teach Pendant: | tak |
| Calibration package: | tak, automatyczna kalibracja |
| Remote system support: | tak |
| Positioning / rotary station: | tak, jeśli potrzebna |
| Separators: | tak |
FAQ
What is BOXY Autoloader ROBORATOR V1?
The BOXY Autoloader ROBORATOR V1 is a compact robotic cell for automating the loading and unloading of CNC machines, including lathes, machining centers, and cylindrical grinders. The manufacturer positions it as a cost-effective solution for small and medium-sized workpieces.
What makes this automation system unique?
The biggest advantage is the ability to operate without programming the robot after a single process definition, as well as 24/7 operation with minimal operator involvement. The source materials also emphasize the compact design, easy relocation, and the preservation of manual operation options.
How does SoftBoxy work?
SoftBoxy is the software for managing the Boxy system, enabling quick and easy programming, even without specialized skills. The system controls the robot, machine tool, and peripherals in a single environment.
What are the basic parameters of detail storage?
The system uses 600 x 400 mm drawers and, depending on the version, can have multiple drawers and a load capacity of up to 50 kg per drawer. Catalog versions for this system family also include the option of additional handles and dividers.
Which machines is ROBORATOR V1 compatible with?
The system is designed for lathes up to 8", vertical machining centers, drilling and tapping centers, and cylindrical grinders. This makes it well-suited for standard manufacturing applications across a wide range of industries.
What are the benefits of such a cell?
ROBORATOR V1 increases machine utilization, improves repeatability, and reduces dependence on employee availability. Additionally, it allows parts to be loaded and unloaded without stopping the robot, reducing downtime.
Is the system safe and compliant with production requirements?
Yes, the station is CE marked, and the offer also includes a safety kit and machine integration. The materials also include a safety scanner and solutions supporting safe work with CNC machines.
For which companies will this be the best choice?
This solution is ideal for companies looking to automate their machining without major investments in specialized systems and without sacrificing flexibility. It's best suited for applications where short changeovers, small- to medium-sized batches, and space savings are key.
