Elite Robots CS625 collaborative robot
SKU: CS625
Elite Robots CS625 – cobot power in its purest form. The Elite Robots CS625 is a true heavyweight in the world of collaborative robots. With an impressive payload of up to 25 kg, this model represents the best and most economical alternative to traditional industrial robots, while offering all the safety and flexibility typical of cobots. The CS625 is designed for tasks requiring strength, stability, and reliability. It excels in heavy-duty workpiece handling, palletizing, packaging, and machine tending, maintaining high precision regardless of load. Its advanced safety systems enable direct interaction with the operator without the need for additional safety barriers. Key features: Load capacity up to 25 kg – maximum performance in its class, Safe operation with humans – built-in collision sensors and dynamic motion control, An economical alternative to industrial robots – lower implementation and operating costs, High precision and stability – ideal for demanding automation processes, Versatile applications – palletizing, moving heavy loads, operating machinery and more, Premium construction – a combination of durability and modern design. Why CS625? The Elite Robots CS625 is the ideal choice for facilities looking for industrial power in a user-friendly package. It combines strength, safety, and intuitive operation, enabling intelligent and efficient automation of the most demanding tasks.
Ask an advisor
Want to know price, configuration or delivery time?
Interested in this machine?
Contact our sales department.
We will respond within 48 hours.
Product description
Elite Robots CS625 – cobot power in its purest form.
The Elite Robots CS625 is a true heavyweight in the world of collaborative robots. With an impressive payload of up to 25 kg, this model represents the best and most economical alternative to traditional industrial robots, while offering all the safety and flexibility typical of cobots.
The CS625 is designed for tasks requiring strength, stability, and reliability. It excels in heavy-duty workpiece handling, palletizing, packaging, and machine tending, maintaining high precision regardless of load. Its advanced safety systems enable direct interaction with the operator without the need for additional safety barriers.
Key features:
- Load capacity up to 25 kg – maximum performance in its class,
- Safe operation with humans – built-in collision sensors and dynamic motion control,
- An economical alternative to industrial robots – lower implementation and operating costs,
- High precision and stability – ideal for demanding automation processes,
- Versatile applications – palletizing, moving heavy loads, operating machinery and more,
- Premium construction – a combination of durability and modern design.
Why CS625?
The Elite Robots CS625 is the ideal choice for facilities looking for industrial power in a user-friendly package. It combines strength, safety, and intuitive operation, enabling intelligent and efficient automation of the most demanding tasks.
Technical Parameters
| SKU: | CS625 |
|---|---|
| Brand: | Elite Robots |
| Workpiece weight (wrist) (kg): | 25.00 |
| Repeatability (mm): | ± 0.08 |
| TCP speed (m/min): | 3.30 |
| Arm weight: | 58.00 |
| Maximum robot payload (kg): | 25.00 |
| Reach radius in (mm): | 1,500.00 |
| Typical TCP speed (Mbps): | 2.00 |
| Number of axes: | 6 |
| Software packages: | tak |
| Teach Pendant: | tak |
| IP protection rating: | 65 / 68 (opcja) |
FAQ
What is Elite Robots CS625 and what is it used for?
The Elite Robots CS625 is a 6-axis cobot with a payload capacity of 25 kg and a reach of 1500 mm, designed for heavier automation tasks such as palletizing, machine tending, pick-and-place, and welding. The manufacturer positions it as the most powerful cobot in the CS series and a cost-effective alternative to traditional industrial robots.
What are the basic parameters of the CS625?
The CS625 has a payload of 25 kg, a reach of 1500 mm, a repeatability of ±0.06 mm or ±0.08 mm depending on the source, and an arm weight of 58 kg. The documentation also includes data on a TCP speed of up to 3.3 m/s, an IP65 rating, and an optional IP68 rating.
What makes the CS625 design unique?
Its greatest advantage is its high load capacity combined with its compact design and relatively low weight, resulting in a good load-to-weight ratio. This makes the robot suitable for heavier applications without sacrificing ease of integration.
What are the main uses of CS625?
The CS625 is suitable for palletizing, packaging, heavy lifting, machine operation, assembly, and welding. Manufacturer and distributor materials also indicate material handling and heavy assembly applications.
What does programming and integration look like?
The robot offers graphical, offline, and Python script programming, as well as extensive connectivity via Ethernet, RS485, Modbus, EtherNet/IP, Profinet, and OPC UA. This facilitates integration with line automation and rapid deployment.
Is the CS625 suitable for collaborative work?
Yes, the CS625 is a cobot designed to work safely alongside humans, without the need for full safety barriers in many applications. The references also highlight its built-in collision sensors and dynamic motion control.
What communication possibilities does it have?
The CS625 features three Ethernet ports, one RS485 port, configurable inputs and outputs, and support for TCP/IP, Modbus TCP/RTU, EtherNet/IP, and Profinet. This connectivity helps it work with a variety of automation systems and peripherals.
For which companies will the CS625 be the best choice?
The CS625 is best suited for facilities that require a very high payload capacity from a cobot while maintaining safety and flexibility. It is best suited for heavier palletizing, internal logistics, and tasks where industrial power is required while maintaining ease of use.
