Tornos SWISS XT 26/8 automatic lathe
SKU: XT-26-8
Tornos SWISS XT 26/8 – a compact, high-performance automatic lathe. The Tornos SWISS XT 26/8 is a compact and versatile CNC automatic lathe designed to produce precision parts with maximum efficiency. Despite its small footprint (3056 x 1440 x 2242 mm), the machine offers a wide range of machining capabilities, combining high performance, flexibility, and ergonomics. Key features: Available variants – ability to work with rods with diameters of 13, 25.4 and 32 mm, Nine linear axes – enables flexibility of the production process, Three independent tool systems – machining with up to three tools simultaneously increases productivity, Plug-and-play B-axis (optional) – even greater flexibility and advanced machining operations, Working range: max. bar diameter 25.4 mm, max. turning length 250 mm (optional 330 mm), Spindle power and speed: up to 10,000 rpm (main spindle), up to 10,000 rpm (sub-spindle), Main spindle power 10.5kW, Sub-spindle power 10.5kW, Optional ACB Plus – advanced chip management and production stability, Compact design – saving space without sacrificing technological capabilities. Benefits for the user: Fast and stable processing – ideal for high-volume production and demanding details, Reduction of machining time – simultaneous machining with 3 tools, Easy programming – simplified control thanks to TISIS software, Production economy – quick transitions between operations thanks to interchangeable tools, Favorable price-performance ratio – the machine combines precision with high profitability, Ergonomics – easy access to the work area and clear operation for the operator. TORNOS SWISS XT 26/8 is an automatic lathe that is ideal for precision mass production – it offers an unparalleled combination of speed, power, compact design and advanced technological capabilities.
Ask an advisor
Want to know price, configuration or delivery time?
Interested in this machine?
Contact our sales department.
We will respond within 48 hours.
Product description
Tornos SWISS XT 26/8 – a compact, high-performance automatic lathe.
The Tornos SWISS XT 26/8 is a compact and versatile CNC automatic lathe designed to produce precision parts with maximum efficiency. Despite its small footprint (3056 x 1440 x 2242 mm), the machine offers a wide range of machining capabilities, combining high performance, flexibility, and ergonomics.
Key features:
- Available variants – ability to work with rods with diameters of 13, 25.4 and 32 mm,
- Nine linear axes – enables flexibility of the production process,
- Three independent tool systems – machining with up to three tools simultaneously increases productivity,
- Plug-and-play B-axis (optional) – even greater flexibility and advanced machining operations,
- Working range: max. bar diameter 25.4 mm, max. turning length 250 mm (optional 330 mm),
- Spindle power and speed: up to 10,000 rpm (main spindle), up to 10,000 rpm (sub-spindle),
- Main spindle power 10.5kW,
- Sub-spindle power 10.5kW,
- Optional ACB Plus – advanced chip management and production stability,
- Compact design – saving space without sacrificing technological capabilities.
Benefits for the user:
- Fast and stable processing – ideal for high-volume production and demanding details,
- Reduction of machining time – simultaneous machining with 3 tools,
- Easy programming – simplified control thanks to TISIS software,
- Production economy – quick transitions between operations thanks to interchangeable tools,
- Favorable price-performance ratio – the machine combines precision with high profitability,
- Ergonomics – easy access to the work area and clear operation for the operator.
TORNOS SWISS XT 26/8 is an automatic lathe that is ideal for precision mass production – it offers an unparalleled combination of speed, power, compact design and advanced technological capabilities.
Technical Parameters
| SKU: | XT-26-8 |
|---|---|
| Brand: | Tornos |
| Number of B-axes: | 2 |
| Maximum turning length (mm): | 250 (330op.) |
| Maximum workpiece length (standard parts catcher) (mm): | 120 |
| Maximum workpiece length (mm): | 110 |
| Number of linear axes (pcs): | 8.00 |
| Rapid traverse rate (m/min): | 30 |
| Maximum spindle speed (rpm): | 10000 |
| Maximum spindle torque (Nm): | 26 |
| Maximum tapping size: | M10x1.5 |
| Maximum drilling diameter (mm): | 10.00 |
| Maximum tapping size on main / sub spindle: | M10x1.5\M10x1.5 |
| Maximum continuous torque (Nm): | 26.00 |
| Maximum spindle speed (RPM): | 10,000.00 |
| Maximum sub-spindle speed (RPM): | 10000 |
| Driven tool speed (rpm): | 8,000.00 |
| Number of radial driven tools: | 4 |
| Total number of driven tools: | 16 |
| Maximum number of turning tools: | 8 |
| Maximum number of fixed axial tools for main / sub-spindle: | 5/5 |
| Maximum number of tools: | 42.00 |
| Maximum speed of main / sub-spindle driven tools (rpm): | 8000 |
| Maximum tap size for driven tools: | M10x1.5\M5x0.8 |
| Maximum drill diameter for driven tools (mm): | 10/6 |
| Driven tools power (kW): | 1/3.1 |
| Number of high-speed driven tools: | 1 |
| Main spindle / sub-spindle tool distribution: | 26/22 |
| Shank Size (mm): | (12x12mm)/(16x16mm) |
| Machine dimensions (length x width x height) (mm): | 3056x1440x2242mm |
| Machine weight (kg): | 3880 |
| Control: | Fanuc 31iB Plus |
| Maximum connected power (kW): | 29.00 |
| Tank capacity (L): | 300.00 |
FAQ
What applications is the Tornos SWISS XT 26/8 intended for?
The SWISS XT 26/8 is designed for precise, multi-series production of bar parts, wherever high efficiency, repeatability and stable cycle time are important in a compact machine size.
What diameter and length of bar can be processed?
The machine handles bars with a maximum diameter of 25.4 mm, and the maximum turning length is 250 mm, with the possibility of extension up to 330 mm, which allows for the efficient processing of both shorter and longer workpieces.
How many axles does the SWISS XT 26/8 have and what does it offer in practice?
The configuration of 8 linear axes plus 2 C axes (for spindles) ensures high process flexibility and enables the implementation of complex operations in a single setup while maintaining short cycle times.
What tooling systems are available on the machine?
The SWISS XT 26/8 offers three independent tool systems, which allows simultaneous machining with up to three tools, significantly increasing productivity and reducing machining time.
What are the parameters of the main and sub spindles?
Both the main and sub-spindles reach up to 10,000 rpm, with power up to 10.5 kW and torque up to 26 Nm, ensuring high dynamics and a stable cutting process in high-volume production.
What is the optional plug and play B-axis for?
The plug and play B axis enables operations at an angle (milling, drilling, chamfering) without complicated machine reconstruction, significantly expanding the range of possible detail geometries.
What is the optional ACB Plus system and what are its benefits?
ACB Plus is an advanced chip management and process stabilization system that improves chip evacuation, reduces chip winding and increases operational reliability during long machining cycles.
What are the benefits of a compact machine design?
With dimensions of 3056 x 1440 x 2242 mm, the machine takes up little space in the hall, while maintaining full technological capabilities and very good access to the work zone, which facilitates operation and servicing.
How does programming and operation of the SWISS XT 26/8 work?
Programming is simplified thanks to TISIS software, which supports the creation and synchronization of programs across multiple channels, and the ergonomic design ensures clear operation for the operator.
How does SWISS XT 26/8 affect production economics?
The ability to work with three tools simultaneously, quick transitions between operations thanks to interchangeable tools and a favorable price-to-performance ratio translate into a low unit cost of the part in mass production.
